产品名称: ML Series Aluminum Housing Single-Phase Running And Starting Capacitor Asynchronous Motor
产品说明: ML series aluminum housing single-phase tow-value capacitor asynchronous motors, with latest design in entirety, are made of selected quality materials and conform to the IEC standard. ML motors have good performance, safety and reliable operation, nice appearance, and can be maintained very conveniently, while with low noise, little vibration, light weight and simple construction. These series motors can be used for air-compressor, pump, fan, medical apparatus and instruments, and many other small machines.
技术参数



Model
Power
Current(A)
Speed
(r.p.m)
Eff(%)
Power facotr
Ist/In
Ist/In
Tmax/Tn
HP
kW
ML711-2 0.37 0.5 2.60 0.95 68 2760 2.2 6.5 1.7
ML712-2 0.55 0.75 3.71 0.95 71 2760 2.2 6.5 1.7
ML801-2 0.75 1 4.92 0.95 73 2780 2.2 6.5 1.7
ML802-2 1.1 1.5 7.02 0.95 75 2780 2.2 6.5 1.7
ML90S-2 1.5 2 9.32 0.95 77 2800 2.2 6.5 1.7
ML90L-2 2.2 3 13.5 0.95 78 2800 2.2 6.5 1.7
ML100L-2 3 4 18.2 0.95 79 2820 2.0 7.0 1.7
ML112M-2 3.7 5 22.1 0.95 80 2820 2.0 7.0 1.7
ML711-4 0.25 0.33 1.90 0.95 63 1360 2.2 6.5 1.7
ML712-4 0.37 0.5 2.64 0.95 67 1360 2.2 6.5 1.7
ML801-4 0.55 0.75 3.76 0.95 70 1380 2.2 6.5 1.7
ML802-4 0.75 1 4.98 0.95 72 1380 2.2 6.5 1.7
ML90S-4 1.1 1.5 7.11 0.95 74 1400 2.2 6.5 1.7
ML90L-4 1.5 2 9.44 0.95 76 1400 2.2 6.5 1.7
ML100L1-4 2.2 3 13.7 0.95 77 1410 2.0 7.0 1.7
ML100L2-4 3 4 18.4 0.95 78 1420 2.0 7.0 1.7
ML112M-4 3.7 5 22.4 0.95 79 1420 2.0 7.0 1.7
