产品名称: MY Series Aluminun Housing Single-Phase Capacitor Running Asynchronous Motor
产品说明: MY series aluminum housing single-phase capacitor-start asynchronous motors，with latest design in entirety，are made of selected quality ma-teriais and to the IEC standard.MC motors have good performance，safety and relible operation，nice appearance，and can be maintained very conve-niently，with low noises，little vibration and at the same time of light weight and compact construction. These series motors can be used for air-compressor，pumps，refrigerator，medical apparatus and instruments，and many other machines needing full-load start.
技术参数



Model Power
(W)		 Voltage
(V)		 Current
(A)		 Speed
(r.p.m)		 Eff
(%)		 Power
factor 		Tst/Tn
 Tm/Tn
MY6312 180 220 1.62 2800 56 0.90 0.8 1.7
MY6322 250 220 2.06 2800 60 0.92 0.8 1.7
MY6314 120 220 1.17 1400 52 0.90 0.9 1.7
MY6324 180 220 1.65 1400 54 0.92 0.8 1.7
MY7112 370 220 2.86 2800 65 0.95 0.7 1.7
MY7122 550 220 4.05 2800 65 0.95 0.7 1.7
MY7114 250 220 2.04 1400 60 0.93 0.8 1.7
MY7124 370 220 2.96 1400 61 0.93 0.7 1.7
MY8012 750 220 5.07 2800 70 0.96 0.65 1.7
MY8022 1100 220 7.16 2800 72 0.97 0.6 1.7
MY8014 550 220 4.05 1400 65 0.95 0.7 1.7
MY8024 750 220 5.52 1400 65 0.95 0.65 1.7
MY90S2 1500 220 9.57 2800 72 0.99 0.6 1.7
MY90S4 1100 220 7.29 1400 70 0.98 0.6 1.7
MY100S4 1500 220 7.55 1400 70 0.90 0.6 1.7
